Introduction
From 2016 to 2022, the Acura CDX was only available in China. It is a stylish, small premium crossover. The CDX became popular in China because it combined Honda’s practicality with Acura’s high-end design and equipment, even though it wasn’t as well-known in the West. The Acura CDX is constructed on the same chassis as the Honda HR-V; thus, it has similar size and mechanical parts, but it’s a little more refined.
When you change or upgrade your wheels, it’s important to obtain the appropriate fit for performance, safety, and looks. We’ll show you all the important wheel specs for the Acura CDX in this article. These include the bolt pattern, rim size, hub bore, offset, and tire size. This shoe has the right measurements for every model, please, from standCHCH to 2022 please.
Overview of Acura CDX (2016–2022)
The Acura CDX is a premium crossover that was created just for Chinese buyers and came out in 2016. GAC Honda made it for Acura as a way to get into China’s growing SUV market. The CDX was built on the same basis as the Honda HR-V, but it had more luxurious features, a sharper appearance, and a turbocharged 1.5L engine with an 8-speed dual-clutch transmission. There were both front-wheel drive and all-wheel drive versions, so there was something for everyone.
The CDX was made for six years, and during that time, it got small changes to its style and trim, but the wheel specs stayed the same. These specs stayed pretty much the same, which makes it easier for owners to choose wheels. Acura also came out with an A-Spec trim that has sharper looks and wheels that are a little broader. The CDX was discontinued in 2022 when Acura left the Chinese market, but it is still a good choice for anyone who wants a small, luxurious car.
Read About: Acura ZDX Wheel Fitment
Acura CDX Wheel Fitment Specifications
To choose the appropriate wheels for your Acura CDX, you need to know the factory wheel specs. The model has a 5×114.3 mm (5×4.5″) bolt pattern and a 64.1 mm center bore. The thread size for lug nuts is M12 x 1.5. The torque standards aren’t officially given; however, it’s safe to follow general rules for Honda-based platforms that are similar.
Most CDX versions have 235/50ZR18 tires on 7.5Jx18 ET45 wheels. The A-Spec model came with 235/45ZR19 tires on 8Jx19 ET45 wheels as an option. The OEM offset is usually between 43 and 47 mm, which gives the car a neutral stance without affecting the suspension or fender clearance.
The CDX can fit wheels that are 18 to 19 inches in diameter, so you can make the car look better without losing ride quality. Here is a complete table that shows OEM specs for different model years:
Acura CDX [2016–2022] Wheel Fitment Table
| Year | Center Bore | Bolt Pattern | Lug Nut Thread | Tire Size | OEM Rim | Offset (mm) | Tire Pressure (Front / Rear, bar) | Aftermarket Wheel Size |
| 2016 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/50ZR18 97W | 7.5Jx18 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2017 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2018 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2019 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2020 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2021 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
| 2022 | 64.1 mm | 5×114.3 | M12 x 1.5 | 235/45ZR19 95W | 8Jx19 ET45 | 43–47 | 2.3 / 2.3 | 18″–19″ |
Aftermarket Wheel Options for Acura CDX
There are a few things you should bear in mind if you want to put aftermarket wheels on your Acura CDX. Most people choose wheels that are 18 or 19 inches in diameter because they look attractive and make the ride comfortable. You can also try bigger rims or custom offsets, but you should stay within the OEM offset range of 43–47 mm to avoid rubbing or suspension problems.
Moving from 7.5J to 8.5J wide wheels is a common upgrade, especially for people who want better grip and stance. Just make sure that the tire width is right for the wheel width. A 245/45R19 or 255/40R19 tire would work well, depending on how much space you have. Always check the inner clearance again, especially at the strut. Also, make sure to take into account the 64.1 mm hub bore to make sure it fits right.
Finally, don’t forget to check that the tire pressure sensors (TPMS) are compatible and that you have the right torque parameters for the lug nuts. These little things make sure that your improvement is both secure and useful.
Wheel Fitment Tips for Acura CDX Owners
There are a few critical things you should do before you buy aftermarket wheels. First, check the bolt pattern on the wheel. The CDX has a 5×114.3 layout, which is typical, but certain wheels could have more than one pattern, so be careful to match it. Next, pay attention to the center bore. Use hub-centric rings to stop vibrations if the wheel’s center bore is bigger than the CDX’s 64.1 mm.
Don’t use severe offsets that push the wheels too far out, because this can cause the fenders to rub or the suspension parts to wear out faster than they need to. The offset range that is safe is between +43 and +47 mm. For lug nuts, use the M12 x 1.5 thread size and make sure the torque is even across the pattern.
Finally, always keep the right amount of air in your tires: 2.3 bar in the front and back. This makes sure that the handling is always the same and the tires last longer. These little things will help you drive smoothly and make your upgrade less stressful.
FAQ’s
Can I fit 20-inch wheels on my Acura CDX?
Some fans do put 20-inch wheels on their cars, but this might cause clearance problems, especially with tight suspension settings. You might need to make a few changes to your suspension or roll your fenders.
Are HR-V wheels compatible with the CDX?
Yes, most of the time. The CDX and the HR-V have the same characteristics because the CDX is built on the HR-V platform. For example, they both have a 5×114.3 bolt pattern and hub bore. But always check the width and offset.
What’s the widest tire I can run without rubbing?
A safe upgrade that many people use is 245/45R19 on an 8.5J rim with the right offset. Before you buy, always try it on or talk to a specialist.
Conclusion
Even though the Acura CDX was only made for a brief time, its design and engineering make it a great choice for new wheels. It’s not too hard to customize your setup because the bolt pattern is always 5×114.3, the hub bore is 64.1 mm, and the wheels can be between 18 and 19 inches in size.
If you want to keep your car’s original specs or make it look sportier with aftermarket wheels, it’s important to follow the right size and offset standards. To make sure that all CDX model years are compatible, use the wheel fitment table in this article. Above all else, make safety and fitment accuracy your top priorities so you can enjoy both performance and peace of mind on the road.
