The Acura CL Type-S is a performance coupe that was made in 2001 and 2003 and is still loved by fans. This car has a sporty V6 engine and a sleek style. It gives you a smooth ride with lots of power. If you want to customize your car or keep it handling well, it’s important to know how to install the wheels correctly. obtaining the bolt pattern, rim size, offset, hub bore, and tire size perfect may make a big difference in how your car looks and how well it works, whether you’re sticking with the existing wheels or obtaining new ones. In this article, we’ll show you everything you need to know about how to properly fit wheels on the 2001 and 2003 Acura CL Type-S models. By the end, you’ll know exactly which wheels will fit correctly and make your driving experience better.
Acura CL Type-S Wheel Fitment Overview
It’s not just about how the wheels look on the Acura CL Type-S; it’s also about keeping the car balanced and easy to handle. The bolt pattern for both the 2001 and 2003 versions is 5×114.3 mm, which is a popular size for many Honda and Acura cars. The factory rim size is usually 17 inches, however the automobile can fit wheels that are 16 to 19 inches in diameter without any problems. The factory offset is between +40mm and +45mm, which means it fits flush without lowering the suspension clearance. The hub bore is 64.1 mm, so any aftermarket wheel should either fit this or be hub-centric with rings. Tire sizes might be different, but 215/50R17 and 225/45R17 are two popular ones. Knowing these fundamental parameters will help you avoid making mistakes that will cost you a lot of money, whether you want a stock look or a more aggressive stance. If you’re changing the suspension or planning a staggered setup, always check the clearances again.
Read About: Acura CL Wheel Fitment
2001 Acura CL Type-S Wheel Fitment
Bolt Pattern, Rim Size & Offset
When choosing new or replacement wheels for the 2001 Acura CL Type-S, it’s important to know that the stock bolt pattern is 5×114.3 mm. The original size of the rim is 17×6.5 inches, and it usually comes with an offset of +45mm. If you’re thinking about getting wheels from a third party, you can safely look at wheels that are 17 to 18 inches wide and 7 to 8 inches wide. An offset of +35mm to +45mm keeps the fit flush and keeps the fenders and suspension from rubbing against one other. Drivers may improve their stance and cornering abilities without sacrificing safety or comfort thanks to this flexibility. It’s crucial to make sure that the total rolling diameter of the tire matches the new rim size so that the speedometer works correctly and the car handles correctly. The appropriate wheel and offset arrangement not only looks better, but it also makes sure that the tires wear evenly and the suspension works as it should.
Hub Bore & Center Bore Size
The hub bore of the 2001 CL Type-S is 64.1 mm, which is a common size for many Acura and Honda models. This size makes sure that the wheel is correctly positioned on the hub, which lowers the likelihood of vibration at greater speeds. Always check the size of the center bore before you buy new wheels. Hub-centric rings will cover the gap if the wheel’s bore is bigger than 64.1 mm. These cheap parts make sure that everything fits well and rides smoothly. Don’t buy wheels with a smaller center bore unless they are made just for your car. They won’t fit. People often forget about the right size of the hub bore, but it is quite important for keeping things in line and avoiding problems like premature bearing wear or wheel imbalance. Before you buy new wheels, take the time to check this information.
Tire Size Compatibility
The standard tire size for the 2001 Acura CL Type-S is usually 215/50R17. This size strikes a good balance between comfort, grip, and fuel efficiency. A common size for an upgrade to an 18-inch wheel is 225/45R18. This keeps the overall diameter close to stock, which is important for keeping the speedometer accurate and the suspension working properly. You can put on wider tires like 235/45R17 or 235/40R18 if you want to improve performance or looks. Just make sure the wheel width and offset are right. But it’s crucial to make sure that the new configuration doesn’t hit the fenders or struts, especially on cars that are lowered. If you need to change something from the factory requirements, always verify fitting instructions or talk to a specialist. If you choose the appropriate tires for your wheels, your Acura CL Type-S will not only look great, but it will also handle and ride the way it was meant to.
Wheel Upgrade Tips for 2001 CL Type-S
There are a few important things to think about when you upgrade the wheels on your 2001 Acura CL Type-S. First, make sure the wheels you choose stay within or very close to the original offset range of +35mm to +45mm. This keeps the wheel level with the fender without making it hard to get to. Second, make sure the new wheels fit the factory hub bore or use hub-centric rings to make sure they fit snugly. If you’re thinking about getting wider wheels, like 8 inches or more, be sure they don’t rub on the inner fender or suspension parts. People don’t often employ staggered setups on front-wheel-drive cars like the CL Type-S, but if you enjoy the look, take in mind that it may not work as well. Lastly, don’t forget how important it is to have the right lug nuts. Some aftermarket wheels need conical or tuner-style lugs. These little things make sure that your wheel update improves the car’s performance and lasts longer.
2003 Acura CL Type-S Wheel Fitment (6-Speed Manual Available)
Bolt Pattern, Rim Size & Offset
The 2003 Acura CL Type-S has the same bolt pattern as the 2001 model: 5×114.3 mm. The biggest change, though, is that it comes with a 6-speed manual transmission, which drew in more performance-minded customers. OEM wheels are once again 17×6.5 inches with a +45mm offset. If you want a more aggressive stance or better grip, 18-inch wheels with offsets between +38mm and +45mm are a good choice. If you choose the right offset and tires, you may put 18×8 wheels on your car without making it hard to drive. Picking the appropriate offset makes that the wheels don’t stick out too much or sit too deep in the wheel well, which could cause rubbing or alignment problems. If you want to get the most out of your 6-speed CL Type-S, think about getting a good performance tire to go with your new wheels. To keep that sporty vibe, it’s important to find the right balance between fit and function.
Hub Bore & Center Bore Size
The 2003 Acura CL Type-S has a 64.1 mm hub bore, much like the older model. This makes it easier to shop for wheels because they will fit the same way in both production years. But since this model might be popular with drivers who want to make performance changes, it’s even more important to get the hub-centric fit correct. A lot of aftermarket wheels have bigger center bores, so hub-centric rings are needed. These rings help keep the wheel centered and decrease vibrations when driving fast. Always double-check the torque specs and select high-quality hardware if you want a configuration that works better. If you’re tracking or driving your manual CL Type-S hard, you need to make sure the hubs are properly engaged to avoid imbalance. It may not seem like a performance tweak to match the hub bore size, but it can make a big difference in stability, steering feel, and braking control.
Tire Size Compatibility
The stock tire size for the 2003 Acura CL Type-S is still 215/50R17, although many fans choose to upgrade to 225/45R17 or even 235/40R18. These sizes give you a bigger footprint, which helps with traction, especially on the 6-speed variant where power goes straight to the wheels. To keep the speedometer accurate, the tire size should be similar to the stock diameter, just how it was with the 2001 model. Depending on how your suspension is set up, wider tires may need lower offsets or fenders that are somewhat rolled. Always check for clearance at full lock and compression if you have coilovers or lowering springs. Choosing all-season or summer tires that are made for performance can also help with braking and turning. It’s important to remember that the quality of the tires is just as important as their size. Cheap tires may fit, but they won’t give you the grip or safety you expect from a performance coupe like the CL Type-S.
Wheel Upgrade Tips for 2003 CL Type-S
Changing the wheels on your 2003 Acura CL Type-S is a terrific way to match the athletic look of its 6-speed manual transmission. To keep the suspension and body panels from getting in the way, start by staying within the safe offset range (+35mm to +45mm). If you’re thinking of 18-inch wheels, choose widths of 8 or 8.5 inches to make them look better and handle better. To get the most out of the added grip, use them with high-quality tires. Also, keep an eye on the unsprung weight; lighter wheels can make a big difference in how well the car rides and how quickly it accelerates. Always use lug nuts that work with the new wheel design, and think about re-torquing them after driving 100 miles. Staggered wheels may look fantastic, but they’re not the best choice for front-wheel-drive cars like the CL Type-S. Instead, focus on square arrangements that keep wear even and handling steady. When done correctly, upgrading your wheels will improve both how they look and how they work.
Recommended Aftermarket Wheel Sizes for Acura CL Type-S
Aftermarket wheels are a great way to make your Acura CL Type-S your own without losing any of its functionality. 17×7.5, 18×8, and even 19×8.5 inches are common sizes for upgrades. These sizes are a good mix of looks and performance. To make sure the fit is right and to keep the fenders and suspension from getting in the way, stay within the offset ranges of +35mm to +45mm. 17-inch wheels provide the car a ride that is almost like stock but looks better. 18-inch wheels give the car a sharper stance and let you use low-profile tires that make cornering easier. If you choose 19-inch wheels, be careful about how comfortable the ride is and make sure the tires don’t go beyond the factory rolling diameter specs. Always utilize hub-centric rings or make sure the hub bore is 64.1 mm to get the right fit. Brands like Enkei, Konig, and Avid make wheels that are compatible with Acura and combine style, durability, and weight savings. When choosing wheel size, think about how you drive. Daily drivers might like 17s, while weekend warriors would like bigger sets.
Acura CL Type-S YA4 [2001–2003]
| Year | Center Bore | Bolt Pattern | Lug Nut Thread | Torque (Nm) | OEM Tire Size | OEM Rim Size | OEM Offset Range (mm) | Tire Pressure (Front / Rear, bar) | Aftermarket Wheel Size Range |
| 2001 | 64.1 mm | 5×114.3 (5×4.5) | M12 x 1.5 | Unknown | 215/50R17 93V | 7Jx17 ET55 | 53–57 | 2.4 / 2.2 | 17″–18″ |
| 2002 | 64.1 mm | 5×114.3 (5×4.5) | M12 x 1.5 | Unknown | 225/45R18 93V | 7.5Jx18 ET50 | — | 2.5 / 2.3 | 17″–18″ |
| 2003 | 64.1 mm | 5×114.3 (5×4.5) | M12 x 1.5 | Unknown | 235/40ZR18 91W | 8Jx18 ET50 | — | 2.5 / 2.3 | 17″–18″ |
Tips for Choosing the Right Wheels for Your Acura CL Type-S
When picking the perfect wheels for your Acura CL Type-S, you should think about your style, performance ambitions, and daily driving needs. To avoid problems with fitment, make sure you keep within the right bolt pattern (5×114.3 mm) and offset range (+35mm to +45mm). Next, think about the width and diameter of the wheels. Wider wheels give you greater grip, but you might have to change the fenders. When you drive every day, 17- or 18-inch wheels are a nice blend of comfort and style. Lightweight wheels can improve handling and acceleration if you’re looking for performance. Don’t forget about the hub bore. It should be 64.1 mm, or use rings to make it fit snugly. Lastly, pick tires that go well with your wheels and don’t change the overall diameter too much. Getting the fitment perfect makes sure that your improvement not only looks good, but also makes your automobile more responsive, safer, and longer-lasting. Wheels are more than simply an adornment; they’re an important aspect of how your car works.
Conclusion
Even though the Acura CL Type-S is no longer being made, it is still a popular choice for people who care about performance and comfort. It’s important to know the right specs whether you’re restoring an original configuration or upgrading to new aftermarket wheels. The 5×114.3 mm bolt pattern, 64.1 mm hub bore, perfect offset, and tire sizes all affect how your car handles, looks, and feels on the road. You may update the wheels on both the 2001 and 2003 models, which lets you make small improvements or big style changes. Plan your setup carefully, and your CL Type-S will provide you a smoother ride, better grip, and a unique look that sticks out. If you always put fitting accuracy ahead of looks, you’ll love every mile you drive.
FAQs
Can I install 19-inch wheels on my Acura CL Type-S?
Yes, as long as you use the right tire size and offset to keep the overall diameter and keep the tires from rubbing.
Will aftermarket wheels affect my car’s ride quality?
They can. Lighter wheels usually make the ride and handling better, but big wheels with low-profile tires could make the ride less comfortable.
Are 2001 and 2003 CL Type-S wheel specs the same?
Yes, they have the same basic characteristics, such as bolt design, hub bore, and offset range.
Do I need hub-centric rings with aftermarket wheels?
Hub-centric rings are necessary for a good fit and ride quality if the center bore is bigger than 64.1 mm.
Is a staggered setup recommended for the CL Type-S?
Not usually, because it’s front-wheel drive, a square arrangement gives superior balance and tire wear.
